Common mode rejection ratio (CMRR) | ≥100dB | ||
The input circuit | Float, defibrillation | ||
Input loop current | ≤0.1чA | ||
Sampling rate | 12bit/1000HZ | ||
Operating mode | Manual/automatic | ||
The filter | Working filter, electromechanical filter | ||
Drift filtering | Anti-drift system | ||
The input impedance | ＞50MΩ | ||
Patient leakage current | ＜10чA | ||
Fuse specification | T1.6A/ 250V Ø5×20 | ||
Recording paper specification | Scroll/folding thermal recording paper (210mm ~ 216mm self-adaptive) | ||
Calibration voltage | 1mV±3% | ||
Polarization resistance voltage | ±300mV | ||
Time constant | ≥3.2s | ||
Frequency response | 0.05-150Hz | ||
Noise level | ≤15чVp-p | ||
Minimum detection signal | ≤20чV | ||
The feeding speed | 12.5 mm/s, 25mm/s, 50mm/s | ||
The sensitivity | 5, 10, 20 (mm/mV ±5 %) | ||
record | Twelve high resolution thermal print | ||
The battery | 14.52V/5.2Ah（75.504Wh） | ||
Overall dimensions | 365mm×306mm×109mm | Net weight: 4.25 KG | |
Size of packing box | 400mm×350mm×200mm | Gross weight: 6.2 KG | |
Product | Model No. | Monitor | Width of printer paper | Auto-analysis | |||
3-Channel | DE-03 | 7” touch screen | 80mm | Yes | |||
6-Channel | DE-06 | 7” touch screen | 112mm | Yes | |||
12-Channel | DE-12 | 10.2” touch screen | 210mm/215mm/216mm | Yes | |||
HE-12 | 13.3” touch screen | 210mm/215mm/216mm | Yes | ||||
Workstation | Connect to PC, adapt to every model of ECG machine | ||||||
